| Stator thickness | 15 mm | tw |
| Number of phases | 3 | nphase |
| Number of coils per phase | 3 | q |
| Total number of coils in stator | 9 | coil_num |
| Number of turns per coil | 48 | Nc |
| Copper wire diameter | 1.4 mm | dc |
| Number of wires at hand | 2 | No_wires_at_hand |
| Winding fill factor | 0.55 | kf |
| Copper wire cross-sectional area | 3.08 mm2 | sc |
| Copper wire cross-sectional area (Calculated) | 2.97685 mm² | sc_theor |
| Copper wire cross-sectional area of a sinlge wire | 1.54 mm² | sc_multi_wires |
| Copper wire diameter (Calculated) | 1.94735 mm | dc_theor |
| Coil leg width | 17.92 mm | wc |
| Average length of coil turn | 208.269 mm | lavg |
| Stator nominal temperature | 80.2603 C° | tc_real |
| Stator surface area | 671.792 cm² | stator_surface_area |
| Heat coefficient | 0.288568 | cq_real |
| Current density | 5.79906 A | Jmax_real |
| Resistivity of copper at nominal temperature | 2.08021E-8 Ohm.m | pt |
| Resistance of a single coil | 0.0675185 Ohm | Rc |
| Phase resistance | 0.202556 Ohm | Rphase |
| Phase inductance | 0.000479856 H | Ls |
| Nagaoka constant | 0.240076 | Kn |
| Winding coefficient | 0.95 | kw |
| Volume of a single coil | 55982.7 mm3 | coil_volume |
| Weight of a single coil | 286.736 g | coil_weight_constr |
| Coil hole at Ravg | 30 mm | coil_hole_Ravg |
| Coil hole at Rin | 30 mm | coil_hole_Rin_constr |
| Coil hole at Rout | 30 mm | coil_hole_Rout_constr |
| Coil mass for construction | 2.86736 kgr | mcu_constr |
| RMS flux linkage of phase A | 0.0232258 Wb | FluxRmsA |
| RMS flux linkage of phase B | 0.0227663 Wb | FluxRmsB |
| RMS flux linkage of phase C | 0.0231372 Wb | FluxRmsC |
| EMF at the cut-in wind speed (Calculated) | 10.264 V | EMF_cut_in |
| EMF at the nominal wind speed (Calculated) | 15.2398 V | EMF_nom |
| RMS of EMF of phase A (Flux Linkage) | 13.262 V | V_rmsA |
| RMS of EMF of phase B (Flux Linkage) | 13.3844 V | V_rmsB |
| RMS of EMF of phase C (Flux Linkage) | 13.2768 V | V_rmsC |
| Current at the nominal wind speed | 17.8611 A | Iac_nom |
| Terminal voltage at the nominal wind speed | 11.2904 V | V_term_line |
| Nominal frequency | 30.8338 Hz | fnom |
| Generator power (Calculated) | 604.978 W | Pnom |
| Generator power (Torque) | 499.511 W | PelN_Torque_x |
| Electromagnetic power (Torque) | 695.957 W | PHMN_Torque_x |
| Copper losses (Calculated) | 193.857 W | Pcopper |
| Copper losses (Torque) | 193.857 W | PcopperN_Torque_x |
| Eddy current losses (Torque) | 2.58802 W | PeddyN_Torque_x |
| Generator efficiency (Torque) | 0.705636 | efftotalN_Torque_x |
| Generator efficiency (Calculated) | 0.73897 | efficiency_real |
| AC Power at the rectifier (Calculated) | 544.48 W | Pnom_rect |
| AC Power at the rectifier (Torque) | 449.56 W | PelN_Torque_x_rect |
| DC Power at the batteries (Calculated) | 490.032 W | Pnom_dc |
| DC Power at the batteries (Torque) | 404.604 W | PelN_Torque_x_dc |
