Prova | Online Design Tools for Locally Manufactured Small Wind Turbines

Submitted by hwerner on Tue, 24/05/2022 - 12:32

Duration:

00:03:01

Tabs

Results

Blade Rotor Outputs
Property	Value	Variable name
RPM at the cut-in wind speed (TSR)	250.796 RPM	n_cut_in
RPM at the nominal wind speed (TSR)	343.443 RPM	n_nom
Nominal tip speed ratio	3.59471	tsr_nom
RPM at the cut-in wind speed (Flux Linkage)	265 RPM	cutin_RPM
Cut-in Voltage (Flux Linkage)	24 V	cutin_Voltage
Wind speed at cut-in RPM (Flux Linkage)	3.1699 m/s	cutin_Vw
Mechanical power (Torque)	485.642 W	Pmech_Torque_x

Generator Rotor Outputs
Property	Value	Variable name
Rotor disk thickness	10 mm	hr
Magnet width-to-pole pitch ratio	0.580193	ai
Inner-to-outer magnet radius	0.622186	kd
Flux density in airgap	0.575675 T	Bmax
Flux density on magnet surface	0.645264 T	Bmg
First harmonic of flux density in airgap	0.522785 T	Bp
Flux per pole (Calculated)	0.000903523 Wb	Flux_pole
Magnets on a rotor disk	12	magnet_num
Distance between magnets	9.6642 mm	dist_magnet_Rin
Magnet mass	2484 g	MagnetMass
Magnet density	7.5 g/cm3	mag_density
Volume of a single magnet	13800 mm3	Vmag
Volume of all magnets	331200 mm3	VolumeMagnet
Remanent magnetic flux density	1.265 T	Br
Magnetic coercivity	982324 A/m	Hc
Maximum Energy Product	326 KJ/m³	BHmax
Outer diameter	245.347 mm	Dout
Average radius	98.753 mm	Ravg
Inner radius	75.753 mm	Rin
Outer radius	122.673 mm	Rout
Effective outer radius	121.753 mm	Rout_eff
Mass of rotor disks	7.44142 kgr	BackIronMass
Volume of rotor disks	945.543 cm3	BackIronVolume
Maximum flux density in the magnet rotor disk	1.12769 T	SaturMAX
Is the magnet rotor disk saturated?	No	Saturation

Generator Stator Outputs
Property	Value	Variable name
Stator thickness	13 mm	tw
Number of phases	3	nphase
Number of coils per phase	3	q
Total number of coils in stator	9	coil_num
Number of turns per coil	36	Nc
Copper wire diameter	1.7 mm	dc
Number of wires at hand	1	No_wires_at_hand
Winding fill factor	0.55	kf
Copper wire cross-sectional area	2.27 mm2	sc
Copper wire cross-sectional area (Calculated)	2.22838 mm²	sc_theor
Copper wire cross-sectional area of a sinlge wire	2.27 mm²	sc_multi_wires
Copper wire diameter (Calculated)	1.68484 mm	dc_theor
Coil leg width	11.4294 mm	wc
Average length of coil turn	187.888 mm	lavg
Stator nominal temperature	70.2152 C°	tc_real
Stator surface area	386.54 cm²	stator_surface_area
Heat coefficient	0.248108	cq_real
Current density	5.88998 A	Jmax_real
Resistivity of copper at nominal temperature	2.00049E-8 Ohm.m	pt
Resistance of a single coil	0.0596092 Ohm	Rc
Phase resistance	0.178828 Ohm	Rphase
Phase inductance	0.00026858 H	Ls
Nagaoka constant	0.254385	Kn
Winding coefficient	0.95	kw
Volume of a single coil	27916.8 mm3	coil_volume
Weight of a single coil	144.893 g	coil_weight_constr
Coil hole at Ravg	30 mm	coil_hole_Ravg
Coil hole at Rin	30 mm	coil_hole_Rin_constr
Coil hole at Rout	30 mm	coil_hole_Rout_constr
Coil mass for construction	1.44893 kgr	mcu_constr
RMS flux linkage of phase A	0.0202065 Wb	FluxRmsA
RMS flux linkage of phase B	0.0198268 Wb	FluxRmsB
RMS flux linkage of phase C	0.0201738 Wb	FluxRmsC
EMF at the cut-in wind speed (Calculated)	10.264 V	EMF_cut_in
EMF at the nominal wind speed (Calculated)	14.1379 V	EMF_nom
RMS of EMF of phase A (Flux Linkage)	12.8488 V	V_rmsA
RMS of EMF of phase B (Flux Linkage)	12.9164 V	V_rmsB
RMS of EMF of phase C (Flux Linkage)	12.8509 V	V_rmsC
Current at the nominal wind speed	13.3703 A	Iac_nom
Terminal voltage at the nominal wind speed	11.2904 V	V_term_line
Nominal frequency	34.3443 Hz	fnom
Generator power (Calculated)	452.867 W	Pnom
Generator power (Torque)	376.559 W	PelN_Torque_x
Electromagnetic power (Torque)	474.964 W	PHMN_Torque_x
Copper losses (Calculated)	95.9038 W	Pcopper
Copper losses (Torque)	95.9038 W	PcopperN_Torque_x
Eddy current losses (Torque)	2.50033 W	PeddyN_Torque_x
Generator efficiency (Torque)	0.775385	efftotalN_Torque_x
Generator efficiency (Calculated)	0.798654	efficiency_real
AC Power at the rectifier (Calculated)	407.58 W	Pnom_rect
AC Power at the rectifier (Torque)	338.904 W	PelN_Torque_x_rect
DC Power at the batteries (Calculated)	366.822 W	Pnom_dc
DC Power at the batteries (Torque)	305.013 W	PelN_Torque_x_dc

Generator Bearing Hub Outputs
Property	Value	Variable name
Number of bolts on hub	4	No_bolts_hub
Mass of bearing hub	3708.65 g	BearingHubMass
Rotational losses (Calculated)	10.6781 W	Prot
Rotational losses (Torque)	10.6781 W	ProtN_Torque_x

Costs, Mass and Volume
Property	Value	Variable name
Total generator cost	327.109 EUR	Totalcost
Total generator mass	12.7577 kgr	TotalMass
Total generator volume	2.78935 dm3	TotalVolume
Blade rotor mass	1.91156 kgr	blade_rotor_mass
Softwood density	500 kgr/m³	softwood_density
Cost of magnets	230.554 EUR	Magcost
Magnet shipping cost	20 EUR	shippingcost
Copper mass	1.2354 kgr	mcu
Cost of copper	18.2345 EUR	coppercost
Resin mass	1.59692 kgr	resinmass
Cost of resin	22.0581 EUR	resincost
Resin volume	1174.2 cm3	ResinVolume
Total mass of one generator rotor	4.96271 kgr	TotalMassRotor
Cost of iron	9.15295 EUR	ironcost
Surface area of moulds	0.297403 m2	woodS
Total cost of moulds	47.1087 EUR	woodcost

Revolutions per minute (RPM)
0
343.443373

I_RMS (A)
0
13.370259

Output files

Octave/Matlab variable file:

simulation-7429.mat

Input parameters

Blade Rotor Inputs

Turbine radius:

1.00m

Aerodynamic coefficient:

0.30

Cut-in wind speed:

3.00m/s

Nominal wind speed:

10.00m/s

Cut-in TSR:

8.75

Design TSR:

7.00

Air density:

1.204kg/m³

Generator Rotor Inputs

AFPM rotor topology:

Double Rotor

Magnetic material:

NdFeB N40

Number of generator poles:

Magnet length:

46mm

Magnet width:

30mm

Magnet thickness:

10mm

Rotor disk thickness:

User Defined

Rotor disk thickness:

10mm

Mechanical clearance:

3.00mm

Generator Stator Inputs

Select coil type:

Rectangular

Winding fill factor:

User defined

Winding fill factor:

0.55

Stator thickness:

User defined

Stator thickness:

13mm

Current density:

6.00A/mm2

System Inputs

System voltage:

24.00V

Nominal voltage:

24.00V

Transmission cable losses:

10.00%

Rectifier losses:

10.00%

Financial

Copper price:

12.00€/kg

Iron price:

1.00€/kg

Resin price:

11.23€/kg

Plywood price:

17.60 €/m²

Simulation Inputs

Also run UserAFPM:

true

Simulation step:

Current step:

RPM Step:

Mesh size:

Automesh

Constants

Copper resistivity:

1.678E-8 Ω·m

Copper density:

8.94g/cm³

Iron density:

7.87g/cm³

Resin density:

1.36g/cm³
