| Stator thickness | 15 mm | tw |
| Number of phases | 3 | nphase |
| Number of coils per phase | 3 | q |
| Total number of coils in stator | 9 | coil_num |
| Number of turns per coil | 50 | Nc |
| Copper wire diameter | 1.5 mm | dc |
| Number of wires at hand | 2 | No_wires_at_hand |
| Winding fill factor | 0.5 | kf |
| Copper wire cross-sectional area | 3.54 mm2 | sc |
| Copper wire cross-sectional area (Calculated) | 3.24493 mm² | sc_theor |
| Copper wire cross-sectional area of a sinlge wire | 1.77 mm² | sc_multi_wires |
| Copper wire diameter (Calculated) | 2.03314 mm | dc_theor |
| Coil leg width | 23.836 mm | wc |
| Average length of coil turn | 212.965 mm | lavg |
| Stator nominal temperature | 48.0289 C° | tc_real |
| Stator surface area | 913.721 cm² | stator_surface_area |
| Heat coefficient | 0.145636 | cq_real |
| Current density | 4.58324 A | Jmax_real |
| Resistivity of copper at nominal temperature | 1.8673E-8 Ohm.m | pt |
| Resistance of a single coil | 0.0561678 Ohm | Rc |
| Phase resistance | 0.168504 Ohm | Rphase |
| Phase inductance | 0.000493674 H | Ls |
| Nagaoka constant | 0.217698 | Kn |
| Winding coefficient | 0.95 | kw |
| Volume of a single coil | 76143.4 mm3 | coil_volume |
| Weight of a single coil | 350.471 g | coil_weight_constr |
| Coil hole at Ravg | 25 mm | coil_hole_Ravg |
| Coil hole at Rin | 7.58095 mm | coil_hole_Rin_constr |
| Coil hole at Rout | 42.3011 mm | coil_hole_Rout_constr |
| Coil mass for construction | 3.50471 kgr | mcu_constr |
| RMS flux linkage of phase A | 0.0253414 Wb | FluxRmsA |
| RMS flux linkage of phase B | 0.0249438 Wb | FluxRmsB |
| RMS flux linkage of phase C | 0.0252585 Wb | FluxRmsC |
| EMF at the cut-in wind speed (Calculated) | 10.264 V | EMF_cut_in |
| EMF at the nominal wind speed (Calculated) | 14.5177 V | EMF_nom |
| RMS of EMF of phase A (Flux Linkage) | 13.8512 V | V_rmsA |
| RMS of EMF of phase B (Flux Linkage) | 13.883 V | V_rmsB |
| RMS of EMF of phase C (Flux Linkage) | 13.8617 V | V_rmsC |
| Current at the nominal wind speed | 16.2247 A | Iac_nom |
| Terminal voltage at the nominal wind speed | 11.2904 V | V_term_line |
| Nominal frequency | 29.3314 Hz | fnom |
| Generator power (Calculated) | 549.549 W | Pnom |
| Generator power (Torque) | 504.189 W | PelN_Torque_x |
| Electromagnetic power (Torque) | 641.285 W | PHMN_Torque_x |
| Copper losses (Calculated) | 133.071 W | Pcopper |
| Copper losses (Torque) | 133.071 W | PcopperN_Torque_x |
| Eddy current losses (Torque) | 4.02556 W | PeddyN_Torque_x |
| Generator efficiency (Torque) | 0.774018 | efftotalN_Torque_x |
| Generator efficiency (Calculated) | 0.779439 | efficiency_real |
| AC Power at the rectifier (Calculated) | 494.594 W | Pnom_rect |
| AC Power at the rectifier (Torque) | 453.77 W | PelN_Torque_x_rect |
| DC Power at the batteries (Calculated) | 445.135 W | Pnom_dc |
| DC Power at the batteries (Torque) | 408.393 W | PelN_Torque_x_dc |
