| Stator thickness | 15 mm | tw |
| Number of phases | 3 | nphase |
| Number of coils per phase | 4 | q |
| Total number of coils in stator | 12 | coil_num |
| Number of turns per coil | 20 | Nc |
| Copper wire diameter | 1.7 mm | dc |
| Number of wires at hand | 5 | No_wires_at_hand |
| Winding fill factor | 0.44 | kf |
| Copper wire cross-sectional area | 11.35 mm2 | sc |
| Copper wire cross-sectional area (Calculated) | 10.663 mm² | sc_theor |
| Copper wire cross-sectional area of a sinlge wire | 2.27 mm² | sc_multi_wires |
| Copper wire diameter (Calculated) | 3.68557 mm | dc_theor |
| Coil leg width | 34.7379 mm | wc |
| Average length of coil turn | 226.32 mm | lavg |
| Stator nominal temperature | 36.7047 C° | tc_real |
| Stator surface area | 1886.85 cm² | stator_surface_area |
| Heat coefficient | 0.0826296 | cq_real |
| Current density | 3.75788 A | Jmax_real |
| Resistivity of copper at nominal temperature | 1.79084E-8 Ohm.m | pt |
| Resistance of a single coil | 0.0071419 Ohm | Rc |
| Phase resistance | 0.0285676 Ohm | Rphase |
| Phase inductance | 0.000100894 H | Ls |
| Nagaoka constant | 0.184668 | Kn |
| Winding coefficient | 0.95 | kw |
| Volume of a single coil | 117928 mm3 | coil_volume |
| Weight of a single coil | 505.219 g | coil_weight_constr |
| Coil hole at Ravg | 30 mm | coil_hole_Ravg |
| Coil hole at Rin | 19.5681 mm | coil_hole_Rin_constr |
| Coil hole at Rout | 40.4605 mm | coil_hole_Rout_constr |
| Coil mass for construction | 6.56784 kgr | mcu_constr |
| RMS flux linkage of phase A | 0.011488 Wb | FluxRmsA |
| RMS flux linkage of phase B | 0.0112517 Wb | FluxRmsB |
| RMS flux linkage of phase C | 0.0114448 Wb | FluxRmsC |
| EMF at the cut-in wind speed (Calculated) | 5.132 V | EMF_cut_in |
| EMF at the nominal wind speed (Calculated) | 22.2452 V | EMF_nom |
| RMS of EMF of phase A (Flux Linkage) | 21.9573 V | V_rmsA |
| RMS of EMF of phase B (Flux Linkage) | 22.2864 V | V_rmsB |
| RMS of EMF of phase C (Flux Linkage) | 22.0091 V | V_rmsC |
| Current at the nominal wind speed | 42.652 A | Iac_nom |
| Terminal voltage at the nominal wind speed | 16.9356 V | V_term_line |
| Nominal frequency | 77.1623 Hz | fnom |
| Generator power (Calculated) | 2167.01 W | Pnom |
| Generator power (Torque) | 2421.43 W | PelN_Torque_x |
| Electromagnetic power (Torque) | 2689.54 W | PHMN_Torque_x |
| Copper losses (Calculated) | 155.91 W | Pcopper |
| Copper losses (Torque) | 155.91 W | PcopperN_Torque_x |
| Eddy current losses (Torque) | 112.203 W | PeddyN_Torque_x |
| Generator efficiency (Torque) | 0.883498 | efftotalN_Torque_x |
| Generator efficiency (Calculated) | 0.765484 | efficiency_real |
| AC Power at the rectifier (Calculated) | 1950.31 W | Pnom_rect |
| AC Power at the rectifier (Torque) | 2179.28 W | PelN_Torque_x_rect |
| DC Power at the batteries (Calculated) | 1755.28 W | Pnom_dc |
| DC Power at the batteries (Torque) | 1961.36 W | PelN_Torque_x_dc |
