| Stator thickness | 13 mm | tw |
| Number of phases | 3 | nphase |
| Number of coils per phase | 3 | q |
| Total number of coils in stator | 9 | coil_num |
| Number of turns per coil | 43 | Nc |
| Copper wire diameter | 1.4 mm | dc |
| Number of wires at hand | 2 | No_wires_at_hand |
| Winding fill factor | 0.55 | kf |
| Copper wire cross-sectional area | 3.08 mm2 | sc |
| Copper wire cross-sectional area (Calculated) | 3.06023 mm² | sc_theor |
| Copper wire cross-sectional area of a sinlge wire | 1.54 mm² | sc_multi_wires |
| Copper wire diameter (Calculated) | 1.97443 mm | dc_theor |
| Coil leg width | 18.5231 mm | wc |
| Average length of coil turn | 210.162 mm | lavg |
| Stator nominal temperature | 71.5883 C° | tc_real |
| Stator surface area | 700.714 cm² | stator_surface_area |
| Heat coefficient | 0.253817 | cq_real |
| Current density | 5.96148 A | Jmax_real |
| Resistivity of copper at nominal temperature | 1.99773E-8 Ohm.m | pt |
| Resistance of a single coil | 0.058615 Ohm | Rc |
| Phase resistance | 0.175845 Ohm | Rphase |
| Phase inductance | 0.000401861 H | Ls |
| Nagaoka constant | 0.213231 | Kn |
| Winding coefficient | 0.95 | kw |
| Volume of a single coil | 50607.1 mm3 | coil_volume |
| Weight of a single coil | 260.409 g | coil_weight_constr |
| Coil hole at Ravg | 30 mm | coil_hole_Ravg |
| Coil hole at Rin | 30 mm | coil_hole_Rin_constr |
| Coil hole at Rout | 30 mm | coil_hole_Rout_constr |
| Coil mass for construction | 2.60409 kgr | mcu_constr |
| RMS flux linkage of phase A | 0.0253122 Wb | FluxRmsA |
| RMS flux linkage of phase B | 0.0247933 Wb | FluxRmsB |
| RMS flux linkage of phase C | 0.0252271 Wb | FluxRmsC |
| EMF at the cut-in wind speed (Calculated) | 10.264 V | EMF_cut_in |
| EMF at the nominal wind speed (Calculated) | 14.8246 V | EMF_nom |
| RMS of EMF of phase A (Flux Linkage) | 14.1974 V | V_rmsA |
| RMS of EMF of phase B (Flux Linkage) | 14.3556 V | V_rmsB |
| RMS of EMF of phase C (Flux Linkage) | 14.2138 V | V_rmsC |
| Current at the nominal wind speed | 18.3614 A | Iac_nom |
| Terminal voltage at the nominal wind speed | 11.2904 V | V_term_line |
| Nominal frequency | 30.2662 Hz | fnom |
| Generator power (Calculated) | 621.921 W | Pnom |
| Generator power (Torque) | 563.298 W | PelN_Torque_x |
| Electromagnetic power (Torque) | 744.698 W | PHMN_Torque_x |
| Copper losses (Calculated) | 177.853 W | Pcopper |
| Copper losses (Torque) | 177.853 W | PcopperN_Torque_x |
| Eddy current losses (Torque) | 3.54732 W | PeddyN_Torque_x |
| Generator efficiency (Torque) | 0.744555 | efftotalN_Torque_x |
| Generator efficiency (Calculated) | 0.756176 | efficiency_real |
| AC Power at the rectifier (Calculated) | 559.729 W | Pnom_rect |
| AC Power at the rectifier (Torque) | 506.968 W | PelN_Torque_x_rect |
| DC Power at the batteries (Calculated) | 503.756 W | Pnom_dc |
| DC Power at the batteries (Torque) | 456.271 W | PelN_Torque_x_dc |
